    KLUBERPHARMA UH1 4

    kluberpharma uh1 4

    Klüberpharma UH1 4-220/4-460 are specially designed synthetic lubricating oils for the lubrication of steel punches and bronze guides in pharmaceutical tablet presses, especially in the field of highperformance manufacture of tablets.

    These lubricating oils offer good wear protection, thus extending the service life of components, as confirmed by oscillation friction wear tests according to DIN E 51834. They also reduce the friction coefficient during start-up of tablet presses and offer improved resistance to bronze. This special property enables a significant reduction in tablet contamination problems occurring in the form of black abrasion particles. Klüberpharma UH1 4-220 has been used very successfully by leading tablet manufacturers for the lubrication of tablet punches.

    Klüberpharma UH1 4-220/4-460 are NSF H1 registered and therefore comply with FDA 21 CFR § 178.3570. The lubricants were developed for incidental contact with products and packaging materials in the food-processing, cosmetics, pharmaceutical or animal feed industries. The use of Klüberpharma UH1 4-220/4-460 can contribute to increase reliability of your production processes. We nevertheless recommend conducting an additional risk analysis, e.g. HACCP.

    • Klüberpharma UH1 4-220/4-460 oils are used for the lubrication of the upper and lower punches and bronze guides in tablet presses. Material / friction combinations:
    • Upper punches made of hardened steel (e.g. 1.23.63) operating against cast iron (e.g. GGG 40).
    • Guide rails made of bronze (e.g. 2.0980.03) Lower punches made of hardened steel (e.g. 1.23.63) operating against cast iron (e.g. GGG 40).
    • Please observe the machine manufacturer's instructions on oil temperature and viscosity selection in the lube chart.
    Characteristics Klüberpharma UH1 4-220 Klüberpharma UH1 4-460
    Article number 029014 029065
    Appearance slightly turbid clear
    Colour space yellow yellow
    Service temperature, lower limit -15 °C -15 °C
    Service temperature, upper limit 110 °C 110 °C
    NSF H1 registration number 122863 143071
    Density, DIN 51757, 20°C approx. 0.85 g/cm³  approx. 0.87 g/cm³
    ISO viscosity grade, DIN ISO 3448, ISO VG 220 460
    Kinematic viscosity, DIN EN ISO 3104 / DIN 51562-1 / ASTM D445 / ASTM D7042, 100°C approx. 28 mm²/s approx. 50 mm²/s
    Kinematic viscosity, DIN EN ISO 3104 / DIN 51562-1 / ASTM D445 / ASTM D7042, 40°C approx. 220 mm²/s approx. 460 mm²/s
    Viscosity index, DIN ISO 2909 ≥ 140 ≥ 160
    Pour point, DIN ISO 3016 ≤ -15 °C ≤ -20 °C
    Minimum shelf life from the date of manufacture - in a dry, frost-free place and in the unopened original container, approx. 36 months 36 months



    kluberpharma-uh1-4.pdf
    • NSF H1 registered and therefore in compliance with FDA 21 CFR § 178.3570.
    • NSF ISO 21469 certified – supports compliance with the hygienic requirements of your production.
    • Compatible with bronze. Reduction in tablet contamination problems (due to incompatibility of bronze with oil) previously occurring in the form of black abrasion particles.
